Wire To Wire Connector
- Automotive Connectors > Wire To Wire Connector
- Part Number :
- MG610686
- Series :
- 312 SERIES
General Feature
- Series
- 312 SERIES
- Material Type
- PA66
- Dimensions
- 18.0*23.0*10.8
Physical Feature
- Sealed
- NO
- Color
- Natural
- Primary Locking Type
- HSG Lance
- Number of Poles
- 2
- TPA
- YES
- Connector Position Assurance
- NO
- Mating Rear Holder
- MG630687
- Pitch(mm)
- 10
- Mating Tab Width(in)
- .312
Electrical Feature
- Wire Range
- 312:AVSS 2.0,AVS 3.0
- Insulation Resistance
- DC 500V 100MΩ MIN
- Contact Resistance
- 3mΩ MAX
- Terminal Transmits(A)
- 30
