Wire To Wire Connector
- Automotive Connectors > Wire To Wire Connector
- Part Number :
- MG611764-5
- Series :
- SSD SERIES
General Feature
- Series
- SSD SERIES
- Material Type
- PBT
- Dimensions
- 33.6*38.7*32.0
Physical Feature
- Sealed
- YES
- Color
- Black
- TPA
- YES
- Primary Locking Type
- HSG Lance
- Number of Poles
- 16
- Mating Connector
- MG641767
- Mating Terminal
- ST740709, ST740686, ST740687, ST740688
- Mating Rear Holder
- MG631766-7
Electrical Feature
- Wire Range
- AVSS(CAVS) 0.3~0.85,AVSS(CAVS) 0.3~0.5,AVSS(CAVS) 0.85~1.25,AVSS 2.0
- Insulation Resistance
- DC 500V 100M Ω MIN
- Contact Resistance
- 050:5mΩ Max,090:3mΩ Max
