Wire To Wire Connector
- Automotive Connectors > Wire To Wire Connector
- Part Number :
- MG614354
- Series :
- 050 SERIES
- Series
- 050 SERIES
- Material Type
- PBT
- Dimensions
- 18.0*22.8*20.5
- Sealed
- NO
- Color
- Natural
- Primary Locking Type
- HSG Lance
- Number of Poles
- 5
- TPA
- YES
- Connector Position Assurance
- NO
- Mating Terminal
- ST730751-3, ST731008-3
- Mating Connector
- MG644352, MG644381
- Pitch(mm)
- 3
- Mating Tab Width(in)
- .050
- Wire Range
- AVSS 0.22, CHFUS 0.22,AVS(CAVS, CAVUS) 0.3~0.5
- Insulation Resistance
- DC 500V 100MΩ MIN
- Contact Resistance
- 5mΩ MAX
- Terminal Transmits(A)
- 5
-
