PCB Connector
- Automotive Connectors > PCB Connector
- Part Number :
- MG643758-7
- Series :
- 030 SERIES
General Feature
- Series
- 030 SERIES
- Dimensions
- 22.0*17.0*15.1
Physical Feature
- Connector Type
- DIP-HZT
- Color
- Brown
- Number of Poles
- 3
- Mating Connector
- MG651434
- Pitch(mm)
- 2
- Mating Tab Width(in)
- .030
Electrical Feature
- Insulation Resistance
- DC 500V 100MΩ MIN
- Contact Resistance
- 5mΩ MAX(Initial)
- Terminal Transmits(A)
- 5
