PCB Connector
- Automotive Connectors > PCB Connector
- Part Number :
- MG646439-5
- Series :
- 025 II SERIES
General Feature
- Series
- 025 II SERIES
- Dimensions
- 15.0*13.2*13.3
Physical Feature
- Connector Type
- SMD-VRT
- Color
- Black
- Number of Poles
- 6
- Mating Connector
- MG657193
- Pitch(mm)
- 2.2
- Mating Tab Width(in)
- .025
Electrical Feature
- Insulation Resistance
- DC 500V 100MΩ Min
- Contact Resistance
- 10mΩ Max(Initial)
- Terminal Transmits(A)
- 5
