Wire To Wire Connector
- Automotive Connectors > Wire To Wire Connector
- Part Number :
- MG651050
- Series :
- 090 II SERIES
- Series
- 090 II SERIES
- Dimensions
- 22.00*22.00*22.00
- Material Type
- PBT
- Sealed
- NO
- Color
- Natural
- Number of Poles
- 8
- TPA
- YES
- Mating Connector
- MG641053, MG642450
- Mating Terminal
- ST730675-3, ST730676-3, ST730677-3
- Pitch(mm)
- 4
- Mating Tab Width(in)
- .090
- Wire Range
- 090:FLALUY 0.75, AVS(CAVS) 0.3~0.5, CIVUS 0.35, CIVUS 0.5, AVS(CAVS) 0.85~1.25, FLALUY 1.25, AVSS 2.0, AESSXF 2.5
- Insulation Resistance
- DC 500V 100MΩ MIN
- Contact Resistance
- 3mΩ MAX (Initial)
- Terminal Transmits(A)
- 10
-
