025250375 FAKRA 54F ASSY
025250375 FAKRA 54F ASSY
Part Number :
MG657067-41
Series :
HYBRID SERIES
첨부파일
General Feature
Series
HYBRID SERIES
Dimensions
53.0*34.0*33.0
Material Type
PBT
Physical Feature
Sealed
No
Color
Light Gray
Number of Poles
54
Primary Locking Type
HSG Lance
TPA
YES
Mating Rear Holder
MG630660, MG630660-4
Mating Connector
MG646294-41, MG646295-2
Mating Terminal
ST730722-3, ST730723-3, ST731409-3, ST731409-g, ST731410-3, ST731410-g, ST731428-3, ST731429-3, ST731430-3, kr00406-20, kr20203-20, kr20301-20
Pitch(mm)
025:3.4/250:9.2
Mating Tab Width(in)
.025 / .250 /.375
Electrical Feature
Wire Range
0.13~0.5/0.5~3.0/3.0~8.0
Insulation Resistance
DC 500V 100MΩ
Contact Resistance
10/3/2mΩ MAX(Initial)
Terminal Transmits(A)
5/25/60
