Automotive
- Automotive Connectors > Terminal > Automotive
- Part Number :
- ST731281-3
- Series :
- 110 SERIES
- Series
- 110 SERIES
- Material Type
- Phosphor Bronze
- Dimensions
- 19.3*4.0*2.9
- Plating
- Pre-Tin
- Sealed
- NO
- Tab Thickness(mm)
- 0.8
- Primary Locking Type
- HSG Lance
- Mating Tab Width(in)
- .110
- Terminal Type
- Straight-Side
- Wire Range
- AVSS 2.0, AVS 3.0
- Insulation Range
- 2.6~3.8
- Terminal Transmits(A)
- 15
- Contact Resistance
- 3mΩ MAX
-
