Automotive
- Automotive Connectors > Terminal > Automotive
- Part Number :
- ST731410-3
- Series :
- C025 SERIES
General Feature
- Series
- C025 SERIES
- Material Type
- Phosphor Bronze
- Dimensions
- 14.85*1.45*2.525
Physical Feature
- Plating
- Pre-Tin
- Sealed
- NO
- Tab Thickness(mm)
- 0
- Primary Locking Type
- HSG Lance
- Mating Tab Width(in)
- .020
- Terminal Type
- Straight-Side
Electrical Feature
- Wire Range
- CHFUS 0.13, 0.22
- Insulation Range
- 0.9-1.05
- Terminal Transmits(A)
- 5
- Contact Resistance
- 10mΩ MAX
