Automotive
- Automotive Connectors > Terminal > Automotive
- Part Number :
- ST731413-3
- Series :
- C060 SERIES
General Feature
- Series
- C060 SERIES
- Material Type
- Phosphor Bronze
- Dimensions
- 14.75*2.50*2.80
Physical Feature
- Plating
- Pre-Tin
- Sealed
- NO
- Tab Thickness(mm)
- 0.64
- Primary Locking Type
- HSG Lance
- Mating Tab Width(in)
- .060
- Terminal Type
- Straight-Side
Electrical Feature
- Wire Range
- CHFUS 0.22
- Insulation Range
- 1.0-1.05
- Terminal Transmits(A)
- 10
- Contact Resistance
- 5mΩ MAX
Series Product
/
-
C060 Female TERMINAL (M)
-
C060 WP Female Terminal (M)
-
C060 WP Male Terminal (M)
-
C060 WP Female Terminal (L)
-
C060 Male TERMINAL (S)
-
C060 Male TERMINAL (L)
-
C060 Female TERMINAL (M)
-
C060 WP Male Terminal (L)
-
C060 Male TERMINAL (L)
-
C060 Female TERMINAL (L)
-
C060 Male TERMINAL (M)
-
C060 Female TERMINAL (L)
-
C060 Male TERMINAL (M)
