Automotive
- Automotive Connectors > Terminal > Automotive
- Part Number :
- ST740632-3
- Series :
- 187 SERIES
General Feature
- Series
- 187 SERIES
- Material Type
- Brass
- Dimensions
- 26.7*6.0*2.4
Physical Feature
- Plating
- Pre-Tin
- Sealed
- NO
- Tab Thickness(mm)
- 0.8
- Mating Tab Width(in)
- .187
- Terminal Type
- Straight-Side
Electrical Feature
- Terminal Transmits(A)
- 20
- Insulation Range
- 2.2-2.6
- Wire Range
- AVS[CAVS]0.85-1.25
- Contact Resistance
- 3mΩ Max
