Automotive
- Automotive Connectors > Terminal > Automotive
- Part Number :
- ST740753-3
- Series :
- 050 SERIES
General Feature
- Series
- 050 SERIES
- Material Type
- Brass
- Dimensions
- 21.75*1.8*2.7
Physical Feature
- Plating
- Pre-Tin
- Sealed
- NO
- Tab Thickness(mm)
- 0.64
- Mating Tab Width(in)
- .050
- Terminal Type
- Straight-Side
Electrical Feature
- Terminal Transmits(A)
- 5
- Insulation Range
- 1.8-2.1
- Wire Range
- AVS,CAVS,CAVUS 0.3-0.5
- Contact Resistance
- 5mΩ MAX
