Wire To Wire Connector

Φ2.0 4M HOUSING
Electronic Connectors > Home Appliance Connectors > Wire To Wire Connector

Φ2.0 4M HOUSING

Part Number
MG620013
Series :
Φ1.3/Φ2.0 SERIES
첨부파일
2D PDF 3D PDF
기술 문의 품질 문의 구매 문의

General Feature

Series
Φ1.3/Φ2.0 SERIES
Material Type
PA6
Dimensions
13.4*13.4*26.8

Physical Feature

Number of Poles
4
Pitch(mm)
6.2
Sealed
NO
Color
Natural
Mating Connector
MG610014
Mating Terminal
ST750207-3, ST750208-3, ST750330-3
GWIT
NO
Operating Temperature
-40℃ ~ 105℃
Flame Rating
V2

Electrical Feature

Terminal Transmits(A)
15
Rated Voltage
300v,(ac/dc)
